Multiline Dynamic Checkweighing

FLEX-500 Multiline Checkweigher Station

FLEX-500 Multiline Checkweigher provides high-accuracy dynamic weight inspection across two conveyor channels simultaneously. Products from 5 g to 1500 g can be verified with ±0.1 g accuracy, while both channels are managed from a single operator interface. Products outside the configured weight tolerance can be automatically removed from the production line.

View Technical Details ↓ Request Information
FLEX-500 MULTILINE
FLEX-500 Multiline Checkweigher Station
Measuring Range 01

5–1500 g

Wide weighing range for different product types.

Accuracy 02

±0.1 g

Precise dynamic weight verification.

Conveyor Channels 03

Dual Channel

Two weighing channels managed from a single screen.

Construction 04

Stainless Steel

Built for industrial production environments.

Product Overview

Parallel weighing. Centralized control.

Multiline checkweighing enables manufacturers to increase weight-control capability by processing products across two conveyor channels simultaneously.

FLEX-500 Multiline performs dynamic weight measurement on two parallel channels while both weighing processes are managed through a single operator interface. Products outside the configured tolerance range can be automatically separated from accepted production without interrupting line flow.

01

Parallel Dynamic Measurement

Two conveyor channels enable products to be weighed simultaneously during continuous production.

02

Single-Screen Control

Both weighing channels can be managed through a single user interface for streamlined operation and access to production statistics.

03

Automatic Rejection

Products outside the specified weight range are automatically removed from the production flow through the integrated reject mechanism.

Technical Specifications

General specifications.

Key technical specifications of the FLEX-500 Checkweigher Station, covering weighing performance, machine construction and system configuration.

01 Performance
Minimum Measuring Range
5 g
Accuracy
±0.1 g
Repeatability
0.1 g
Maximum Capacity
Up to 250 pcs/min*
02 Machine
Machine Dimensions
1030 × 1200 × 2170 mm
Construction
Stainless Steel
Voltage / Frequency
110 / 220 V — 50–60 Hz
Reject Mechanism
Piston or Air Nozzle
03 Controls & Options
Operator Interface
Industrial Touch Screen
Software Compliance
GAMP 5 / 21 CFR Part 11
UPS
Optional
Wi-Fi
Optional
Maximum production capacity may vary depending on product dimensions, weight and production-line conditions.
Technology Reference

Developed by VISIOTT TPS.

The FLEX-500 Multiline Checkweigher Station presented on Checkweigher Solutions is developed by VISIOTT TPS. For official product information, technical specifications, manufacturer details and further information about VISIOTT TPS checkweighing technologies, visit the manufacturer's website.
